~ 340 - 370 $
Brand
Model year
2015
  • Aluminum body and XT-7 side plate
  • C4+ rotor
  • Cold forged aluminum spool
  • Screw-in folding aluminum handle
  • HAGANE GEAR
  • X SHIP
  • G FREE BODY
  • ARC SPOOL
  • S ARB
  • ONE PEICE BAIL
  • CI4+
  • HAGANE BODY
  • RIGID SUPPORT DRAG
  • CORE PROTECT

15 Twin Power key features:

S A-RB

S A-RB

Shielded Stainless Steel Anti-Rust Bearings. These bearings have undergone a special heat treatment resulting in high metal strength. Shielded A-RB bearings use either a rubber shield or stainless steel shield (depending on bearing size) for the ultimate in corrosion resistance and contaminant protection against sand, salt or dust.

X-SHIP

X-SHIP

X-Ship provides improved gear durability. By supporting the pinion gear on both ends with bearings, the pinion gear maintains precise alignment with the drive gear. This allows the gears to stay in the same position under the heaviest loads. The added benefit of X-Ship technology is that friction between the spool shaft and gear are eliminated. This further benefits anglers with enhanced casting performance and casting distance of lighter lures.

HAGANE

HAGANE

Hagane is a Shimano reel design concept created to withstand continual use and extreme abuse. Hagane is an innovation with built-in toughness and durability that works alongside Shimano's precision engineering.

HAGANE GEAR

HAGANE GEAR

With amazing strength and durability, the HAGANE Gear is at the very heart of most Shimano reels. Shimano, through the application of state-of-the-art technologies, gives anglers the long-lasting smoothness and pleasure that is felt when anglers first use a reel, over and over again. No cutting work is applied to the teeth of the drive gear during fabrication, instead the entire surface is calculated in minute detail by special 3D-design and then formed by Shimano's cold-forging technology.

HAGANE BODY

HAGANE BODY

The HAGANE Body is a metal reel body with high rigidity. The body rigidity and impact resistance virtually eliminates body flexing on the reel while fighting fish. The result transforms the angler's actions directly into cranking power, increasing efficiency through strength.

AR-C SPOOL

AR-C SPOOL

The spool has a special spool ring shape. This creates a rectifying effect on the line and realizes both suppression of line trouble and long casting performance.

ONE-PIECE BAIL

ONE-PIECE BAIL

One-Piece Bail allows the line to travel unimpeded to the line roller. The seamless design reduces friction and decreases the chance of tangles or the line catching on the bail arm.

CI4+

CI4+

CI4 is a Shimano original material reinforced with carbon fiber that is lighter and has a higher strength than conventional resin material. CI4+ is an advanced version of the original CI4 material and is 2.5x more rigid than its predecessor. While improving lightness and rigidity, reel bodies and rotors built with CI4+ are further reduced in size and weight.

G-FREE BODY

G-FREE BODY

G-Free Body technology has been developed to shift the reel's center of gravity closer to the rod. By moving the center of gravity closer to the angler’s hand, the G-Free Body helps to reduce fatigue and enhance casting comfort.


15 Twin Power lineup:


15 Twin Power specification:

Model Size Bearings Gear ratio Weight Drag power Line per cranck Line capacity Handle position Approx. Price
15 Twin Power 1000PGS 1000 9+1 4.3:1 195.00 GM / 6.88 OZ 3.00 KG / 6.60 LB 57.00 CM / 22.40 IN PE/M: 0.6/140, 0.8/100, 1/70 Left hand, Right hand ~ 340 $
15 Twin Power C2000S 2000 9+1 5.0:1 195.00 GM / 6.88 OZ 3.00 KG / 6.60 LB 66.00 CM / 26.00 IN PE/M: 0.6/150, 0.8/110, 1/80 Left hand, Right hand ~ 350 $
15 Twin Power C2000HGS 2000 9+1 6.0:1 195.00 GM / 6.88 OZ 3.00 KG / 6.60 LB 31.10 CM / 26.00 IN PE/M: 0.6/150, 0.8/110, 1/80 Left hand, Right hand ~ 350 $
15 Twin Power 2500S 2500 9+1 5.2:1 240.00 GM / 8.47 OZ 4.00 KG / 8.80 LB 76.00 CM / 29.90 IN PE/M: 0.6/200, 0.8/150, 1/110 Left hand, Right hand ~ 350 $
15 Twin Power 2500HGS 2500 9+1 6.0:1 240.00 GM / 8.47 OZ 4.00 KG / 8.80 LB 88.00 CM / 34.60 IN PE/M: 0.6/200, 0.8/150, 1/110 Left hand, Right hand ~ 350 $
15 Twin Power C3000 3000 9+1 5.2:1 245.00 GM / 8.64 OZ 9.00 KG / 19.80 LB 76.00 CM / 29.90 IN PE/M: 1/400, 1.5/270, 2/180 Left hand, Right hand ~ 360 $
15 Twin Power C3000HG 3000 9+1 6.0:1 245.00 GM / 8.64 OZ 9.00 KG / 19.80 LB 88.00 CM / 34.60 IN PE/M: 1/400, 1.5/270, 2/180 Left hand, Right hand ~ 360 $
15 Twin Power C3000XG 3000 9+1 6.4:1 245.00 GM / 8.64 OZ 9.00 KG / 19.80 LB 93.00 CM / 36.60 IN PE/M: 1/400, 1.5/270, 2/180 Left hand, Right hand ~ 360 $
15 Twin Power 3000HGM 3000 9+1 5.8:1 265.00 GM / 9.35 OZ 9.00 KG / 19.80 LB 85.00 CM / 33.50 IN PE/M: 1/220, 1.2/150, 1.5/135 Left hand, Right hand ~ 360 $
15 Twin Power 4000PG 4000 9+1 4.4:1 290.00 GM / 10.23 OZ 11.00 KG / 24.00 LB 70.00 CM / 27.60 IN PE/M: 1/500, 1.5/320, 2/210 Left hand, Right hand ~ 370 $
15 Twin Power 4000HG 4000 9+1 5.8:1 290.00 GM / 10.23 OZ 11.00 KG / 24.00 LB 93.00 CM / 36.60 IN PE/M: 1/500, 1.5/320, 2/210 Left hand, Right hand ~ 370 $
15 Twin Power 4000XG 4000 9+1 6.2:1 295.00 GM / 10.41 OZ 11.00 KG / 24.00 LB 99.00 CM / 39.00 IN PE/M: 1/500, 1.5/320, 2/210 Left hand, Right hand ~ 370 $
